Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner

Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner

spot welding robot

C Type Welding Gun

X Type Welding Gun

Place of Origin:

China

Brand Name:

HWASHI

Certification:

CE/CCC/ISO

Model Number:

HS-R8-06

Contact Us
Request A Quote
Product Details
Product Name:
Hwashi Heavy Duty Spot Welding Robot With C Type And X Type Welding Gun For Storage Shelf Corner
Condition:
New
Warranty:
12 Months
Service Life:
8-10 Years
Voltage:
220/380v
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiation
Packaging Details
sea worthy wooden package
Delivery Time
7-30 working days after received your payment
Payment Terms
T/T, L/C
Supply Ability
50 sets per month
RELATED PRODUCTS
Contact Us
Product Description

Hwashi Heavy Duty Spot Welding Robot With C Type And X Type Welding Gun For Storage Shelf Corner

Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner 0

Description

HWASHI welding robot is compact, with small size, which is a dedicated arc welding robot. This robot equipped with international Brands welding power, can achieve a stable welding, access to high-precision welding path, shorten the welding cycle, with high repeat positioning accuracy, fast running, welding process stability, high consistency of the weld, and can shorten the product replacement cycle, The corresponding equipment investment. Widely used in automotive and accessories, motorcycles and accessories, engineering machinery and other metal welding field.

1. Improve the labor intensity of workers, can work in harmful environment.
2. Shorten the production preparation cycle, reduce enterprise investment.
3. Stabilize and improve the welding quality of work pieces.
4. Reduced requirements for workers to operate skills.
5. Simple operation, convenient for users.



P​arameters

Model HS-R6-08 HS-R6-10 HS-R6-20 HS-R6-50 HS-R6-165
DOF 6
Driving Mode AC Servo Driving
Effective Load 8KG 10KG 20KG 50KG 165KG
Repeat Accuracy ±0.05mm
Working radius 1400mm 1589mm 1595mm 1950mm 2483mm
Weight 180KG 180KG 290KG 600KG 1300KG
Motion Range(°) J1 ±170 ±170 ±170 ±180 ±180
J2 ±120~-85 ±120~-80 ±132~-95 ±130~-90 ±80~-60
J3 ±85~-165 ±85~-165 ±73~-163 ±75~-210 ±80~-190
J4 ±180 ±180 ±180 ±360 ±360
J5 ±135 ±135 ±133 ±115 ±115
J6 ±360 ±360 ±360 ±360 ±360
Max Speed(°/s) J1 130 130 147 158 100
J2 130 130 100 149 90
J3 130 130 135 130 104
J4 270 270 300 215 144
J5 170 170 198 251 160
J6 455 455 194 365 215
Power 4KVA 4KVA 6KVA 14KVA 31KVA
Voltage 380V or 220V
Frequency 50Hz or 60Hz

Application and Samples

1. The Six-station positioner layout can realize long time continuous welding, welding efficiency and welding quality has been significantly improved;
2. The positioner realizes the workpiece clamping at one time, and automatically realizes the alternating welding of the four corners of product, the deformation is effectively controlled.
3. This machine can achieve automatic welding with manually loading material. It can also improve the welding quality and welding efficiency. What’s more, it can reduce the production cost. The problem of unstable quality and low production efficiency caused by pure manual operation has been solved.
4. Robot replace manual welding. Welding industry is a high-risk industry, high temperature, arc light and welding smoke have a certain impact on the physical and mental health of workers;
5. It is an inevitable trend to use robots to replace welding robots in welding, which is not only the promotion of the market, but also the requirement of technological upgrading.



Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner 1

Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner 2

Welding Solutions

1. The complete welding robot system includes 4 sets of HS-R6-08 1.4m arm length robot, 4 sets of 350A MIG welding machine, 4 sets of automatic anti-collision welding gun, 1 set of one-axis horizontal rotation positioner, 2 sets of welding gun cleaner, and 6 sets of welding fixtures, etc.
2. In order to guarantee the stability and consistency of welding quality, we suggest to equip with welding gun cleaner device.
3. Automatic welding is carried out by the six-axis robot MIG welder. The cylinders or fast clamps are used to fix the position of the product with the lever principle to ensure the positioning requirements of automatic welding of the robot, so as to ensure that it can be welded to each part of the product. According to the requirements of production efficiency, 1 big rotary table positioner with six stations are designed, 4 fixtures for loading of the workpiece, 1 fixture for welding, and 1 for unloading.

Heavy Duty Spot Welding Robot C Type X Type Welding Gun For Storage Shelf Corner 3



Working Process

1) Manual loading of the workpiece to the fixture in Station 1 fixed table;

2) Start welding;

3) The robot and welding machine will do welding on the workpiece according to the presetting program;

4) Welding completed;

5) While the station 1 is being welded, station 2 is being loaded and fixed the work piece synchronously. Two stations work alternately.

6) Cycle working
