100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder

3 phase spot welder

100KVA Spot Welding Machine

portable spot welding machine

Place of Origin:

China

Brand Name:

HWASHI

Certification:

CE/CCC/ISO

Model Number:

WL-MF-100K

Contact Us
Request A Quote
Product Details
Product Name:
100KVA PLC Controlled Three-Phase Medium Frequency DC Spot Welding Machine For Silver Contact And Copper Sheet
Application:
Welding Of Silver Contact And Copper Sheet
Size:
800x1300x1780mm
Weight:
450kg
Condition:
New
Warranty:
12 Months
Standard:
CE/CCC/ISO
Service Life:
8-10 Years
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiation
Packaging Details
sea worthy wooden package
Delivery Time
7-30 working days after received your payment
Payment Terms
T/T, L/C
Supply Ability
50 sets per month
RELATED PRODUCTS
Contact Us
Product Description

100KVA PLC Controlled Three-Phase Medium Frequency DC Spot Welding Machine For Silver Contact And Copper Sheet

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 0

DESCRIPTION of 100KVA PLC Controlled Three-Phase Medium Frequency DC Spot Welding Machine For Silver Contact And Copper Sheet
Medium frequency inverter DC resistance control system: Refer to the following picture, the three-phase AC current has been rectified into DC.

1.High quality,high efficiency.98% power factor,three-phase input load balancing,the impact on the

user grid has been greatly reduced, DC input current, smooth,inductance is zero. 1000HZ working frequency, time control precision is 1MS

2.High strength body structure, good rigidity, direct pressurizing mechanism, linear bearings used in the guiding structure enable good mobility

3.Adopt high-speed microprocessors,use intelligent optimal calculation method, LCD interface,can save 101sets welding schedule numbers. There are functions of switch display in both Chinese and English,provide external BCD call interface,system fault diagnosis alarm automatically.etc

4.Specially suitable for welding higher conductive rate of material (such as aluminum,copper,silver and so on) and much more thicker workpiece,widely used in automobile,aerospace and other high request products and industry.



Medium Frequency Welding System Composition
Welding Controller, transformer, and welding work piece.
Welding controller includes the controlled rectifier, energy storage part,IGBT,power driving and central control part.

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 1

Intelligent welding control system

Intelligent Touch Screen Controller
Input and read welding parameters.

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 2

Raw materials made to standard

Thicker Copper Plate or Copper Belt To ensure stable conductivity in welding

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 3

Custom processing of electrodes

Customized Electrodes which will be suitable for Welding material like steel,

aluminium, silver, stainless Steel, and nickel steel.

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 4

Shape structure and welding method

Design the right machine shape and mold according tothe welding product.



Compared with the normal AC controller, MF controller has the following advantages
1. The current in secondary welding loop is DC.
2. The weight of transformer is reduced greatly. It is light and convenient.
3. Prolong the service life of electrode.
4. Be able to weld material like aluminum, galvanized steel, etc.
5. Less splashes.
6. Increase control of current and welding quality.




Specification

Parameter/Model MF-50K MF-90K MF-150K MF-170K MF-250K

MF-300K

Rated Voltage 3 phases,(AC), 380 or 415 or 480V, 50/60HZ.
Rated Capacity 50KVA 90KVA 150KVA 170KVA 250KVA 300KVA
Rated Duty Cycle 50% 50% 50% 50% 50% 50%
Max Welding Current 18000A 25000A 32000A 40000A 60000A 80000A
Electrode Stroke 60MM
Welding Arm Spacing 380MM
Air Source Pressure 0.6MPa
Cooling Water Flow 16L/Minute 25L/Minute 35 L/Minute 45L/Minute


Application of 100KVA PLC Controlled Three-Phase Medium Frequency DC Spot Welding Machine For Silver Contact And Copper Sheet

100KVA DC Portable Spot Welding Machine For Silver Contact Cooper Sheet 3 Phase Spot Welder 5
Products like Sensor, LED and its lead, copper foil and vanished wire, relay, watch, capacitive slug and lead, copper wire, resistance pin, inductance, battery and stabilizer link, socket, silver contact and copper sheet, welding lightning with tungsten and molybdenum material, etc.
