75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils

pneumatic spot welder

AC Spot Welding Machine of Kitchen utensils

75KVA spot welder

Place of Origin:

China

Brand Name:

HWASHI

Certification:

CE/CCC/ISO

Model Number:

WL-SP-75K

Contact Us
Request A Quote
Product Details
Product Name:
HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils
Size:
700x900x1780mm
Condition:
New
Standard:
CE/CCC/ISO
Application:
Welding Of All Metal
Weight:
300kg
Warranty:
12 Months
Service Life:
8-10 Years
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiation
Packaging Details
sea worthy wooden package
Delivery Time
7-30 working days after received your payment
Payment Terms
T/T, L/C
Supply Ability
50 sets per month
RELATED PRODUCTS
Contact Us
Product Description

HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 0

DESCRIPTION of HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils

HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils utilizes the general mains supply to lower the voltage and increase the electric current. Such kind of low voltage but large current will be transmitted from the electrode to the linked point of two work pieces. On the linkage, due to the resistance of work piece, high temperature will occur so the metal will therefore generates high heat to make the work pieces in molten condition. Thus, the purpose of welding the two work pieces is achieved. It can be used to weld 10mm of iron and metals like stainless steel. Applicable to all kinds of hardware. Powerful and strong welding current and precise current control. In order to welding different thickness of products, conduction angle of silicon controlled rectifier is divided into 1000 parts for asjusting. Using digital integrated circuit control, strong anti-interference ability, stable and reliable work. Control circuit calls the built-in voltage fluctuation compensation circuit, which can guarantee the power supply fluctuation within + 15% range in a timely manner to make current compensation, ensure stable welding current.



FEATURES of HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils

  1. Intelligent microcomputer type controller.
  2. Easy to adjust the welding power and welding current.
  3. Wide application, firm welding, no loose welding, Sparks can be quite effectively resisted
  4. Convenient operation, easy adjustment.
  5. Pneumatic control (action output).​

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 1

Intelligent welding control system

Intelligent Touch Screen Controller
Input and read welding parameters.

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 2

Raw materials made to standard

Thicker Copper Plate or Copper Belt To ensure stable conductivity in welding

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 3

Custom processing of electrodes

Customized Electrodes which will be suitable for Welding material like steel,

aluminium, silver, stainless Steel, and nickel steel.



APPLICATION of HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils

HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine Of Kitchen Utensils are suitable for iron wire products, hardware decorative lighting, kitchen utensils, automobile industry, small household appliances, small hardware, etc.

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 475KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 5



SPECIFICATION of HWASHI WL-SP-75KVA Resistance Pneumatic AC Spot Welding Machine of Kitchen Utensils

Model

Input Voltage

V

Rated Power

KVA

Max. Short Circuit Current

KA

Duty Cycle

Electrode

Pressure

KG

Electrode Stroke

mm

Cooling Water

L/min

WL-SP-75K 380 1PH 75 28 25 1000 100 8
WL-SP-100K 380 1PH 100 31 25 1000 100 10
WL-SP-150K 380 1PH 150 34 25 1000 100 10

75KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 675KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 775KVA Pneumatic Spot Welder AC Spot Welding Machine Of Kitchen Utensils 8
