Place of Origin:
CE/CCC/ISO
Brand Name:
HWASHI
Certification:
CE/CCC/ISO
CNC 3 Axis Control Stainless Steel Kitchen Sink Seam Welding Machine is a method that uses a pair of roller electrodes instead of the cylindrical electrodes of spot welding, and the welded workpiece moves between the rollers to produce a sealed weld with a molten core overlapping each other to weld the workpiece together.
|
Model
|
WL-AMF-160K
|
Input Power (V/φ)
|
380V 3φ
|
|
Rated Power (KVA)
|
160/250KVA (as per material thickness)
|
|
Applicable Material
|
Stainless Steel 304/201
|
|
Material Thickness
|
0.8~1.5mm (customized)
|
|
Effective Welding Length
|
1600-3000mm (customized)
|
|
Effective Welding Width
|
600-800mm (customized)
|
|
Sink Bowl Shape
|
Square/Rectangular/Round
|
|
Welding Efficiency
|
about 40-60sec/bowl (depend on the size of bowl)
|
|
|
Max. Moving Speed
|
500mm/sec
|
Belt Rotation Speed
|
1200R/min
|
|
Min. Radius
|
R40
|
|
Rated Air Pressure
|
0.6MPa
|
|
Grinding Efficiency
|
about 60-80sec/bowl (depend on the size of bowl)
|
