Product Description

HWASHI IBC Cage Frame Hole Making And Punching Machine Used To Form The Hole Of Frame

IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 0



Description of HWASHI IBC Cage Frame Hole Making And Punching Machine Used To Form The Hole Of Frame

HWASHI IBC Cage Frame Locking Machine Suitable For Locking The Ends Of The Tube Frame The machine frame is processed as a whole, with high precision, stable and efficient operation.

1.The machine is controlled by human-machine interface +PLC programming control mode, with high degree of automation.

2.Simply change the mold block, you can meet the needs of different pipes for punching, and the mold is easy to change.

3.The servo hydraulic system has the characteristics of fast response, small inertia and high precision.

4.High degree of modularization of each part of the equipment, which can be configured to improve the degree of automation according to customer requirements.



IBC Tank Cage Frame Production Line Machine

This automatic production line is mainly used to manufacturing the IBC cage frame. It is composed of cage frame automatic welding, mesh unloading mechanical arm, mesh turnover structure, automatic frame bending machine, locking machine, hole making and punching machine, automatic production line moving mechanical arm. The complete line requires only 3-4 person. Operator only need to do the material loading to the frame welding machine, and do unloading at the end of the line. Also we can equip the line with automatic base frame welding machine and automatic unloading mechanical arm for the base frame.

IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 1 IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 2
Six-Head IBC Frame Automatic Welding Machine
The welding power is designed with 4 sets of MF DC power source. It can do 6 spots welding at one time. Double layer fixture feeder. When one fixture is under welding, another fixture can be loaded with material.
Flat Tube Mesh and Firm Welding Quality
The welding machine will weld the tube into flat mesh type. Firm and strong welding quality. It will take about 60sec to complete the welding process.
IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 3 IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 4
Vertical Double Station IBC Frame Bending Machine
IBC cage frame double station bending machine is processed as a whole to ensure high bending precision, stable operation and high efficiency.

Bend the Flat Mesh into Square Shape



The bending machine will bend the flat mesh into square frame. It will takes about 20- 25sec to complete the bending process.

IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 5 IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 6
IBC Cage Frame Locking Machine
IBC cage frame locking machine is processed as a whole, with high insertion precision, large fastness to locking, stable and efficient operation.
Locking Efficiency and Quality
The locking machine will lock the ends of the tube frame using hydraulic force. It will takes about 25-30sec to complete the locking process.
IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 7 IBC Cage Frame Hole Punching Machine Used To Form The Hole Of Frame 8
IBC Cage Base Frame Welding Machine
The base frame welding machine design adopts horizontal structure and 7 welding heads for completing the welding of base frame. The operator only need to load and unload the product. The machine will do the welding automatically.
Final Product of Base Frame
We can add the automatic loading and unloading device for the base frame welding machine as per your requirement. The welding efficiency is about 15-20 sec/pc.

Technical Parameters of HWASHI IBC Cage Frame Hole Making And Punching Machine Used To Form The Hole Of Frame

NO ITEM PARAMETER
1 Max. Working Size 1200x1000mm (tolerance±5mm)
2

Punching Shape

(customized)
3 loading method Manual or Automatic
4 punching Efficiency 15-25s/p
5 Punching Force

Hydraulic+Pneumatic



Running Process Of The IBC Cage Frame Automatic Production Line
Frame welding——bending——locking——hole punching——unloading——base frame welding——base frame loading——manual screw for base frame and outer frame
